The Moroso 63585 Billet Electric Water Pump is engineered for high-performance applications on Small Block Ford engines, including 289, 302, and 351W. This electric water pump eliminates the need for a mechanical fan and belt drive, reducing parasitic drag and freeing up horsepower. Its billet aluminum construction ensures durability and efficient cooling, making it ideal for street and strip applications.
Key Features:
-
Part Number: 63585
-
Engine Compatibility: Ford Small Block 289, 302, 351W V8s
-
Material: Billet aluminum housing and impeller
-
Finish: Clear anodized for corrosion resistance
-
Inlet Size: -16 AN female port
-
Height: 4.620 inches
-
Weight: Approximately 6.23 lbs
-
Voltage Compatibility: 12V and 16V systems
-
Amperage Draw: 7.00 amps
-
Flow Rate: 30–37 GPM at 12 volts
-
Mounting: Direct bolt-on to stock water pump location
-
Seal: High-temperature Viton® seal to prevent leaks
-
Hardware: Includes stainless steel mounting hardware and gasket
This pump is designed to accommodate lower radiator hoses from either driver or passenger side installations. Its compact design and lightweight construction make it a perfect choice for performance enthusiasts seeking improved cooling efficiency and reduced engine load.
Installation Notes:
-
Hose Adapter: A -16 AN to 1-1/4" hose adapter may be required, depending on your radiator hose setup.
-
Electrical Connection: Ensure proper wiring to a 12V or 16V power source, with appropriate fusing and relays as needed.
-
Compatibility: Verify compatibility with your specific engine build, particularly regarding clearance and hose routing.
